SUS 304 Silver Gray Beverage Mixing System for Juice Filling
Capping
1. WATER STORAGE TANK
Characteristics
1.Stainless steel storage tanks can withstand higher pressures and
are widely used in many high pressure applications.
2.At the same time, stainless steel storage tanks have a remarkable
feature: the tank sealing performance is excellent, completely
eliminating the air.
3.Intrusion of harmful substances and mosquitoes ensures that the
liquid stored in the tank is not contaminated by the outside and
does not breed red worms.
4.The stainless steel tank has strong corrosion resistance, it is
not corroded by residual chlorine in the outside air and water, and
its service life can reach more than 100 years under normal
pressure.
Technical Parameter
Effective volume | Dimension of tank | Total height | Diameter of inlet&outlet |
| (L) | (mm*mm) | (mm) | (mm) |
| 1000 | 1060*1220 | 2550 | 51 |
| 1500 | 1160*1500 | 2850 | 51 |
| 2000 | 1340*1500 | 2900 | 51 |
| 3000 | 1410*2000 | 3400 | 51 |
| 4000 | 1620*2000 | 3450 | 51 |
| 5000 | 1810*2000 | 3500 | 51 |
| 6000 | 1980*2000 | 3550 | 51 |
| 7000 | 1930*2440 | 4000 | 51 |
| 8000 | 2060*2440 | 4000 | 51 |
| 9000 | 2180*2440 | 4050 | 51 |
| 10000 | 2300*2440 | 4050 | 51 |
2. BLENDING TANKS
Main information
*The other two feed inlets are connected with the pipeline for
continuous feeding of various ingredients.
*The insulation materials of the tank are polyurethane foam or
pearl cotton which is high temperature resistant, anti - aging.
*The stirring speed of the agitator is optional.
*The equipment consists of Cylinder body, cylinder cover, mixing
oar, feed inlet, discharge valve and all the parts are made of
stainless steel 304.
*There is a stirring paddle inside which is used to mix well.
*The bottom of the cylinder is inclined, which makes it easy to
empty.
*Nozzle is equipped with level gauge (static pressure type,
capacitance type, non-contact type, ultrasonic type, glass tube),
air breathing, thermometer (digital display type or dial), CIP
cleaning mouth, sight glasses, explosion-proof lamp (optometric
lights integration), SIP sterilizing mouth, liquid inlet and outlet, sanitary manhole, etc.
Technical Parameter
| Effective volume | Dimension of tank | Total height | Diameter of inlet&outlet | Motor power | Blending speed |
| (L) | (mm*mm) | (mm) | (mm) | (kw) | (r/min) |
| 1000 | 1060*1220 | 3150 | 51 | 0.75 |
Common rotation speed 35,43,60, stepless speed reducer or dual-speed reducer are also available
|
| 1500 | 1160*1500 | 3350 | 51 | 0.75 |
| 2000 | 1340*1500 | 3410 | 51 | 1.1 |
| 3000 | 1410*2000 | 4000 | 51 | 1.5 |
| 4000 | 1620*2000 | 4250 | 51 | 1.5 |
| 5000 | 1810*2000 | 4300 | 51 | 2.2 |
| 6000 | 1980*2000 | 4550 | 51 | 2.2 |
| 7000 | 1930*2440 | 5000 | 51 | 2.2 |
| 8000 | 2060*2440 | 5000 | 51 | 3 |
| 9000 | 2180*2440 | 5050 | 51 | 3 |
| 10000 | 2300*2440 | 5050 | 51 | 3 |
