Carbonated CO2 Mixer Beverage Mixing Machine Energy Drinks Mixing
Description
- The beverage mixer is designed to improve the proportion of water,
syrup and carbon dioxide.
- It uses advanced foreign technology-static mixer to reduce the
water layer, increase the carbonization time and ensure the
beverage mixing effect.
- It uses carbon dioxide to deoxidize and save carbon dioxide.
- It also achieves the purpose of deoxidation; high-quality automatic
control system consisting of pumps and electrical appliances, with
the advantages of coordinated action, beautiful appearance,
convenient cleaning and high degree of automation, suitable for
mixing of various types of beverages. Such as soft drinks, soft
drinks such as soda, juice drinks, cola.
- Mixer machine is using injecting gas-water mixer is specially
designed for soda and non-soda drinks such as lemonade, cola and
juice, as well as for other soft drinks such as mineral water,
grape juice, juice wine and apple juice.
- In comparison with other domestic equipment of the same kind, it
achieves functional completeness, great adaptability, a new
structure, nice appearance, and high automation, action
coordination, continuing production, good mixing and excellent
electric control.
- The volume ratio of CO2 and 1L water is 2. 5 to 2. 8.
Features
- Mix well and match the ratio. Due to the advanced technology of
one-time mixing, the mixing is uniform, and the mixing ratio of
water and sugar is strictly controlled by a metering needle valve
with fine adjustment, and the precision can reach about five
thousandths.
- The gas content is sufficient and the number is one. The mixer
adopts vacuum deoxidation at normal temperature, the deoxidation
rate is over 90%, and is equipped with a plate heat exchanger to
cool the syrup mixture for secondary carbonation, so the gas
content is extremely high.
- Self-cleaning and sanitation. This machine is equipped with an
in-situ cleaning device, which can automatically clean and
disinfect the inside of the mixer and filling machine without
disassembling any parts (container-type pipes). The beverage
produced by this machine has a bacterial proliferation rate of
<5% per ml. E. coli is zero and meets the requirements of
international food hygiene standards.
Technical Parameter
| Type | RM 1500 | RM 3000 | RM 4000 | RM 5000 | RM 6000 |
| Production Capacity (kg/h) |
1000 - 1500
|
2500 - 3000
|
2000 - 4000
|
2500 - 5000
|
4000 - 6000
|
| Adjust Proportion of Syrup and Water |
1:3 1:10
|
1:3 1:10
|
1:3 1:10
|
1:3 1:10
|
1:3 1:10
|
| Gas Qty | 1.5-2.5 | 2.5 | 2.5 | 2.5 | 2.5 |
| Cool Water Entry Temperature () |
0 - 5
|
| Working Pressure (MPa) |
0.05 -0.15
|
| Storage Tank Working Pressure (MPa) |
0.2 -0.5
|
| Power (KW) | 1.5 | 3.7 | 4.05 | 5.6 | 6.2 |
| Dimension (mm) | 900 * 700
*2000 | 1720 * 1140
*2100 | 1860 * 1300
*2100 | 1960 * 1400
*2150 | 2020 * 1500
*2200 |
| Weight (kg) | 500 | 1100 | 1300 | 1600 |
1800
|
Our Company
RELIABLE supply the followings machines for you
1) Water treatment equipment---RO purified equipment, UF purified
equipment, Sand filter, Carbon filter, Water softner, Sea Water
treatment.
2) Filling Machine---3 in 1 Washing filling capping---for your
water,cabonated drink,
juice,wine,vinegar, milk,tea and so on.
----150 to 2000ml bottle, 3.5-10L,11- 20L bottle (3-6gallon bottle)
---PET bottle, Glass bottle, PP bottle and Can
----Screw cap, Aluminum cap, Grown cap and three (four) twist caps
etc.
3) Labeling Machine---Stick label, Shrink sleeve label, Hot melt
Opp labels. Wet gule label
4) Printer , Manual code printer , Inkjet printer , Laser printer
5) Packing Machine----Shrink film, Cartons packing machine
6) Bottle Blowing Machine--- for making plastic bottle
7)Injection Molding Machine---for your cap and proform.
8) Subsidiary products for drink production---Bottle Washer, Bottle
Capper, Conveyor, Bottle Dryer, Bottle Warmer, Bottle Loading
system, Bottle unscrambler, CIP system, Bottle Cooler, Bottle
Sterilizer, Blending tank, Storage Tank, Sugar Melting Pot, Syrup
Filter Conveyor and so on.
