Opp Hot Melt Glue Bottle Labeling Machine for Pure Water Plastic
Bottles
Introduction
---7000-1000BPH
Labeling machine with High accuracy and high speed ,which widely
use in pharmaceutical,beverage,food, cosmetic,medicine, daily
chemical ,cultural goods and other industries. It's suitale for
various kinds of bottles types and other products,for example:round
bottle,square bottle,flat botthe,curved bottle,Metal
bottle,cans,paper/plastic bags,paper or plastic boxes,etc.
Advantages
1. It is easy to adjust the label cutting knife, easy and accurate
to use hand handle to adjust the position of cutting knife, the
vacuum drum is made of high rigid material to minish friction and
static.
2. Changing the bottle parts within ten minutes.
3. The vacuum manifold at the lower part of drum and cutter is made
of heat & wear resistant material.
4. This machine with advantage of compact design, floor space, used
for many different bottles, high production capacity etc. It is the
best choice for clients.
5. Microcomputer continuously variable control system
6. Automatic detection in accordance with the feed
7. Automatic adjustment of the production rate to maintain the
labeling machine always in the best production rate
8. Applying the star wheel feeding, to ensure not pour the bottle
under high speed
Technical Parameter:
| Main engine size (length*width*height) | 4000L x 1500W x 1800H mm |
| Main engine production speed | limitation: 7500bph |
| Main engine power supply | AC 3 phase220-380V |
| Main engine power | 8kw |
| Label material | OPP feed roll Paper |
| Label length | 10mm -330mm |
| Bottle/can diameter | 50- 106 mm |
| Junction line error | +/-1.5mm |
Auto cutting and Sticking circle or half circle of bottle. Auto
melting and attaching glue on top and rear of the label , glue auto
recycling .
Variable speed control system, synchronous automatic detection
system, automatic adjust production speed, Always make the labeling
machine at best production speed
Servo motor synchronous tracking, with special designed vacuum drum
adsorption, labeling precise and stable
