PET HDPE Wide Mouth Bottle Blowing Machine With Multi Cavity Mould
Quick Details
Type | RM-6000D |
output | according to bottle shape | 5000-6000PCS/H |
product specification | bottle body diameter | 20mm-100mm |
bottle height | 50mm-350mm |
bottle mouth diameter | 15mm-38mm |
mold | cavity | 6 cavities |
mold thickness | 200mm |
mold effective area | 800*800mm |
Main power | power ,voltage | 380v 3 Phase /220v 3Phase 50/60HZ |
Install machine power/actural use power | 68kw / 15kw |
air source | low pressure air compressor | 1.6m3/min 1.0MPa |
high pressure air compressor | 2.5m3/min 3.0MPa |
cold dry machine | 2.0m3/min 3.0MPa 1set |
cooling water | cooling quantity | 15L/min |
main machine size | L*W*H | 2808*1958*1920mm/4600kg |
feeder size | L*W*H | 2000*950*2480mm/250kg |
Characteristics
1. Utilization of automatic central lubrication.
2. Compact space design for convenience of mold conversion,
repairing, and maintenance.
3. Minimized transfer pitch for increasing heating efficiency and
saving energy.
4. Swift exchange design for preform mandrels.
5. Optimized air flow in the oven for stable heating process.
6. Easy to adjust, exchange and access heating oven; Protection for
preform thread against heating.
7. Intact rotating robot grip with linear guider for right access,
rapid motion; reducing adjustment and maintenance time.
8. Electronic inspector for ejecting faulty preform and bottles.
9. Fast, safe, and accurate cam-controlled blowing wheel for
providing the best bottles.
10. Precise control of blowing technique to produce less-weighted
bottle.
FAQ
Q1: Are you a trading company or a manufactory?
A1: We own a factory ourselves, and we can assure the quality we
manufactured.
Q2: What’s your guarantee or the warranty of the quality if we buy
your machines?
A2: We offer you high quality machines with high quality
after-service. Also we have one year warranty of the spare parts,
free of charge.
Q3: When can I get my machine after I paid?
A3: We will deliver the machines on time as the date we agreed both
side.
Q4: How can I install my machine when it arrives?
A4: We will send our engineer to your side as soon as you get all
your machines ready , for testing and teaching your technicians how
to run the machines.
Q5: How about the spare parts?
A5: After we deal down all the things , we will offer you a spare
parts list for your reference.
What service Reliable Machinery Co.,Ltd can offer you ?
• Your inquiry related to our product & price will be replied
within 24hours
• Well trained & experienced staff are to answer all your inquiries
in English and Chinese
• Working time: 8:30am ~6:00pm, Monday to Friday(UTC+8).
• OEM & ODM projects are both available
• Your business relationship with us will be confidential to any
third party.
• Good after-sale service offered, please get back to us if you got
any questions
