Reliable Brand High Quality Fresh Watermelon Juice Production Line
Technical Parameters
Model | CGFR8-8-3 | CGFR12-12-6 | CGFR18-18-6 | CGFR24-24-8 |
Rinsing Head | 8 | 13 | 18 | 24 |
Filling Head | 8 | 12 | 18 | 24 |
Capping Head | 3 | 6 | 6 | 8 |
RatedCapacity | 2000BPH | 4000BPH | 7000-8000BPH | 10000-12000BPH |
Overall Size(mm) | 1900*1420*2000mm | 2200*1600*2300mm | 2450*1900*2300mm | 2750*1180*2400mm |
Weight(Kg) | 1.5T | 2.2T | 3.0T | 4.0T |
Power(KW) | 3.0kw | 3.5kw | 4.0kw | 4.8kw |
Rated Voltage | 380V | 380V | 380V | 380V |
Machine Description
The Fresh Juice filling machine is designed specially for bottle
tea, juice and other kinds of functional drinks.
1. Center filling valves used which are maximum flow rate and
minimum bottle distortion during HOT filling.
2. Inbuilt CIP arrangement provided on the machine for fill tank
and fill valve sanitation.
3. Dummy caps provided fitting on all filling valve CIP.
4. Automatic PLC controlled valve washing cycle before commencement
of every production cycle for overall hygiene.
5. Unique filling cam designs which prevents filling up to the
bottle collar without spillage.
6. Bypass line provided for flushing the product fill tank after
completion of CIP
7. Supper heavy stainless steel juice tank build in.
Company Introduction
Brief Introduction | Zhangjiagang Reliable Machinery Co., Ltd.is a hi-tech designing and
manufacturing enterprise, which is specialized in beverage
production and packing complete lines as well as various water
treatment machines.We are one of the earliest companies engaged in
manufacturing liquid filling and packing equipment in China |
Main Products | Liquid filling machines (water, fruit juice / tea, carbonated
drink, oil, alcohol, plant protein drink, etc.), Barreled filling
line (3-5 gallon) Water treatment machines, Labeling & packing
machines, semi-automatic / full automatic bottle blowing machines,
and injection molding machines. |
Good Service | we also supply technique consultation, factory construction design
plan, equipment installation and adjustment, technology training
and other after-sales services.Now our products are exported to
over ten countries and regions, including Southeast Asia, Russia,
the Commonwealth of the Independent States, Western Asia and South
Africa. |
Reliable Brand High Quality Fresh Watermelon Juice Production Line
How to get your suitable machine or production line ?
Find our products through Reliable Machinery Co.,Ltd in Google
,Baidu. Bing ,Yahoo, Alibaba.com etc
Enquiry: Contact us by email, phone call, fax, Instant Messenger
(Trademanager, MSN, Skype) and let us know your enquiry.
Discussion: Specify the items you desire, confirm specification;
OEM/ODM consultation.
1.What kind of products will you produce ?
2.What is the capacity(per hour) you want ?
3.What kind of package , plastic bottle ,glass bottle : volume
,height ,neck diameter ,diameter of bottle or
other please inform us of details ?
4.Sole machine or whole production line ?
Quotation: Prices offered and accepted.
Place order as per contract or discussion.
Perform invoice( sales contract ) In duplicate confirmed and kept
by both sides.
Payment settled.
Order completed under our arrangement.
Goods shipped as per contracted term.
Goods arrive at local port or warehouse, depending on contracted
term.
