Machine Descriptions:
Our CGFA Series Machine is mainly used for the water filling,
adopts the principle of gravity filling. The production capacity of
CGFA24-24-8 water filling machine can up to 8000 bottles per hour,
it has three parts, the washing, filling and capping part. Each
machine element that contacts with the liquid is made of high
quality stainless steel. They obtain the advantage of good abrasive
resistance, high stability, low failure rate,etc. The quality of
the equipments reaches the international advanced level.
Features :
1. This machine works harmoniously with air-conveyor belt, It holds
the bottles by the neck, thus, reducing the possibility of bottles
falling over during conveying process.
2. This machine is used to fill water into pet bottle and with
screw caps capping function.
3. This machine integrated three function:
1. Rinse the empty pet bottle, 2. filling the rinsed bottles, 3.
capping the filled bottles
Electric Part & Safe Device & Automation:
1. When accident system automatic stop & alarm
2. Emergency switch when accident
3. PLC , Touch-screen Control Panel & inverter
4. Food Grade 304 stainless steel rinsing pump, reliable & sanitary
Technical Parameters
| Number of heads: 24 Rinsing heads,24 Filling heads,8 Capping heads |
| Applicable bottle size: PET bottle |
| Diameter: ф50-110 mm |
| Bottle height: 150～340mm |
| Rated Capacity 10000BPH 500ML |
| Cap Style Plastic Screw Cap 28mm or 30mm Neck for PET Small Bottles |
| Volume: 250～2000ml |
| Timing Type: Transducer |
| Washing Drop dryer time: 3.4sec |
| Filling temperature: 0-4℃ |
| Compress air wastage: 20NM3/hour |
| Pressure of washing: 0.25-0.3Mpa |
| Pressure of filling : 0.15~0.35Mpa |
| Overall size: 2950*2100*2400mm |
Weight: About 4500KGS |
Power : 4.8KW 3 Phases AC 380V 50Hz or by your order |
Machine Detailed Parts:
Rinser Station:
1. All 304 stainless steel rinser heads, water spray style inject
design, more save water consumption & more clean
2. 304 Stainless steel Gripper with plastic pad, ensure minimal
bottle crash during washing
3. 304 stainless steel washing pumps
Filler Station:
1. High precision filling nozzle, PLC variable signal control,
ensure high filling precision & filling smoothly& steadily,
2. All 304 stainless steel contact parts & liquid tank, fine
polish, easy to clean
3. No bottle no filling
Capper station:
1. Place & capping system, electromagnetic capping heads, with
burden discharge function, make sure minimum bottle crash during
capping
2. All 304stainless steel constructio
3. No bottle no capping
